CNC Fiber Laser Tube Cutting Machine Vector 6005 T.OVL

The Vector 6005 T.OVL is a dedicated fiber laser tube cutting machine for through-cutting of round and profile tubes. It processes workpieces up to 400 mm in diameter and 6 meters in length with a repeat positioning accuracy of ±0.05 mm. Unlike universal sheet lasers with an optional pipe module, the entire mechanical system of the 6005 T.OVL — from the chuck to the steady rests — is engineered specifically for continuous tube work.

Key Advantages of the Vector 6005 T.OVL:

• The W-axis enables cutting at any angle, including weld bevels, without stopping and repositioning the part. Complex contours, holes, and cutouts are completed in a single cycle.
• The clamp automatically adapts to the workpiece cross-section, ensuring rotational concentricity and zero runout — even on long tubes.
• Additional supports prevent deflection and vibration in thin-walled or heavy tubes during rotation, preserving cut quality along the full length.
• Axis drives eliminate backlash on reversal — critical for intricate cutouts and repeatable features.
• The welded steel frame is machined in a single setup, providing a continuous flat plane for the linear guides and ensuring geometric stability across the entire 6-meter working field.
• A modern CNC system with a touchscreen display supports drawing import from CAD/CAM packages and allows the operator to monitor all cutting parameters in real time.

Applications:

• Structural steel fabrication: columns, trusses, frame elements
• Mechanical engineering: chassis parts, hydraulic pipework
• Furniture manufacturing: table frames, shelving, retail fixtures
• Architectural metalwork: space frames, fencing, handrails
